Best For: Retail entrances, driveways and business access areas needing a wide fixed view and people or vehicle detection.
Vivotek FD9383-HV 5MP Outdoor AI Dome Camera with 2.8mm Lens – Black
The black Vivotek FD9383-HV combines 5MP imaging with AI activity detection and a fixed 2.8mm lens. Its black housing suits darker mounting surfaces, with IP66 weather protection and IK10 impact resistance for outdoor installation.
Available from CTC Communications with Australia-wide delivery. Match the lens coverage, recording platform and power source to your site.
Key Features
- 2560 × 1920 (5MP).
- 2.8 mm fixed, F2.0.
- 120 dB WDR Pro for high-contrast lighting.
- Built-in infrared illumination up to 30 m.
- No built-in microphone or audio interface specified.
- IP66 / IK10.
- AI Smart Motion Detection for people and vehicles; Smart VCA.
- H.265 compression and Smart Stream III.
Lens and Camera Coverage
The fixed lens gives a consistent wide view. Position the camera around the area you need to monitor, allowing enough image detail at important entrances and activity points.
Motion Detection and Recording
AI Smart Motion Detection helps distinguish people and vehicles from other movement. Configure event zones and sensitivity around relevant activity. Smart VCA event availability depends on firmware, configuration and the selected management platform; confirm any advanced analytics licence requirements.
WDR Pro and Infrared Night Viewing
WDR Pro helps retain detail where bright and shaded areas meet. Infrared illumination supports black-and-white viewing in darkness, with a rated range of up to 30 m. Illumination range does not guarantee identification at that distance; framing and site conditions determine useful image detail.
Technical Specifications
| Brand / Model |
Vivotek / FD9383-HV (2.8mm) – Black |
| Camera Type |
Outdoor network dome |
| Maximum Resolution |
2560 × 1920 (5MP) |
| Frame Rate |
30 fps at 2560 × 1920 |
| Image Sensor |
1/2.8" progressive CMOS |
| Lens |
2.8 mm fixed, F2.0 |
| Field of View |
103.4° H / 75.3° V / 135.2° D |
| WDR |
120 dB WDR Pro |
| IR Illumination |
Up to 30 m |
| Compression |
H.265 / H.264 / MJPEG; Smart Stream III |
| Detection |
AI Smart Motion Detection for people and vehicles; Smart VCA |
| Audio |
No built-in microphone or audio interface specified |
| Recording |
microSD / SDHC / SDXC up to 1TB and supported NAS |
| Power |
IEEE 802.3af PoE Class 3 |
| Power Consumption |
8.5 W IR on / 6 W IR off |
| Housing |
IP66 / IK10 |
| Working Temperature |
−30°C to 55°C IR off; −30°C to 50°C IR on |
| Dimensions / Weight |
117.2 × 89.6 mm; 550 g |
Power and System Requirements
Arrange a compatible PoE source, network cabling and recording storage. Confirm mounting accessories, memory card requirements and recorder compatibility with CTC. Storage retention depends on capacity, bitrate, resolution and recording schedule.
