Rosslare AC-020 Dual Door, PC Programmable 2 Reader Controller(500 User)

Rosslare AC-020 Integrated Two-Door Access Controller – Compact, Secure, All-in-One Solution

Model: AC-020

The Rosslare AC-020 is a powerful, integrated 2-door access controller designed to simplify and secure access management for small to mid-sized facilities. This compact all-in-one unit supports up to 500 users across two doors and provides full control through PIN codes, proximity cards, or a combination of both.

With dual reader support, built-in power supply, strike relays, and tamper protection, the AC-020 is ideal for securing main entrances, server rooms, or sensitive access points in commercial and industrial sites.

Built for flexibility and ease of installation, the AC-020 includes user-friendly onboard programming with visual and audio feedback via LEDs and an internal speaker.

🔑 Key Features:

• Two-Door Controller: Integrated control for two doors in a single compact unit

• 500 User Capacity: Manage access via PIN, proximity card, or both

• Supports Two Readers: Compatible with PIN and/or proximity readers

• Built-in Power Supply: Includes internal supply for readers, strikes, and inputs

• REX Inputs: Two request-to-exit inputs for smooth egress

• User-Friendly Setup: Program locally via the onboard keypad with LED & sounder guidance

• Internal Speaker: Provides doorbell tones and alerts for tamper and alarms

⚙️ Professional Features:

• Tamper Detection: For both readers and main unit (cover/cable cut protection)

• Fail-Safe/Fail-Secure Strike Relays: Two Form C relay outputs

• 2 User Levels: Master and Normal access roles

• 3 Security Modes: Adjustable for each door

• Battery Backup Support: Built-in charger for external backup battery

📋 Specifications:

• Brand: Rosslare

• Product Type: Keypad & Reader / Controller

• Warranty: 60 Months

• Power Output: 12VDC, 1.2A max for locks

• Capacity: 500 users (PIN/Prox), 2 doors
