Aiphone DA-1ASK Single-Door Audio Intercom Kit with Handset

SKU APHDA-1ASK
by Aiphone
Availability:
In stock

The Aiphone DA-1ASK audio intercom kit includes a DA-1DS aluminium-cover door station, DA-1MD indoor handset and compatible power supply. Features private full-duplex audio, two-wire intercom connection, backlit directory and compatible AC door-strike control. Designed for one entrance and one indoor handset.

Save 22% Save 22%
Original price $380.91
Original price $380.91 - Original price $380.91
Original price $380.91
Current price $298.00
$298.00 - $298.00
Current price $298.00

Shipping & Returns

$19.99 flat-rate shipping Australia-wide

Free shipping on orders over $850


Aiphone DA-1ASK Single-Door Audio Intercom Kit with Handset

The Aiphone DA-1ASK provides private handset communication between one entrance and one indoor answering point. Supplied with a DA-1DS door station, DA-1MD handset and compatible power supply, it lets you speak with visitors before operating a correctly connected electric strike.

Best For

Homes, offices and reception areas needing a simple one-door-to-one-handset audio intercom. A practical choice for voice-based visitor screening and compatible door release without video screens or smartphone setup.

What’s Included

  • 1 × DA-1DS: Single-call audio entrance station.
  • 1 × DA-1MD: Indoor audio handset station.
  • 1 × compatible power supply: System power.

Key Features

  • Private handset conversation: Full-duplex audio for speaking naturally with visitors.
  • Hands-free entrance: Callers speak through the outdoor door station.
  • Two-wire intercom connection: Links the entrance and indoor handset.
  • Compatible door release: Powers a suitable strike from the door station without an additional strike transformer.
  • Backlit directory: Helps visitors identify the call point.
  • Call-volume control: Adjustable call tone with a mute indicator.
  • SERVICE button: Operates a compatible auxiliary function when correctly wired.

Technical Specifications

Model / SKU DA-1ASK / APHDA-1ASK
System type Wired, audio-only single-door intercom
System capacity 1 entrance station and 1 indoor handset
Door station DA-1DS, one call button
Indoor station DA-1MD handset
Power supply Compatible AC power supply included; use the supplied Australian-market unit
Communication Full-duplex handset audio indoors; hands-free at the entrance
Intercom wiring 2 conductors between entrance and handset
Power wiring Separate 2-conductor power-supply connection
Door release 9.5–20V AC strike, resistance 70Ω or greater; Aiphone specifies EL-12S
Strike connection Wired to the door station; compatible release powered by the system
Call settings Call-tone volume adjustment with mute indicator
Auxiliary control SERVICE button for a compatible external function; additional wiring required
Directory Backlit
Door-station cover Aluminium, silver finish
Door mounting Surface mounted
Optional call extension Compatible call-extension sounder, supplied separately
Handset dimensions 89 W × 200 H × 63 D mm
Door-station dimensions 100 W × 175 H × 22 D mm
Operating temperatures Indoor handset: 0°C to +40°C; door station: −10°C to +60°C

Downloads

Installation Information

Confirm cable type, distance and electric-strike compatibility before installation. The strike must meet the DA Series AC voltage and resistance requirements; Aiphone specifies the EL-12S. Electric strikes, cable and installation accessories are separate items. Use the power supply supplied for the Australian kit.

This kit serves one entrance and one handset. Contact our team if you need multiple answering points or video access. CTC Communications offers professional installation across Sydney Metro, with discounted rates in Seven Hills.

Shop with Confidence at CTC Communications

  • Warranty: 3-year manufacturer warranty.
  • Labour warranty: 1 year on installations performed by CTC Communications.
  • Delivery: Australia-wide shipping.

Explore our Aiphone intercom range and home intercom solutions.

Speak with Visitors Before Opening Your Door

Order the Aiphone DA-1ASK online or contact our team to confirm a suitable door strike and installation.

Contact CTC Communications or call 1300 552 282.


Aiphone Intercom Warranty
  • Aiphone products are covered by a 3 year Manufacturer Warranty.
  • Exclusion are labour for products installed by others.
  • CTC Communications provides a 1 year Warranty on labour when the security product is installed by our Team.
  • Freight Cost is excluded from Warranty, unless the product is dead upon arrival.
