Best For: FSH FES10 and FES10M electric strike installations requiring additional latch clearance on timber or aluminium door frames.
FSH FES10-EL15 15mm Extension Lip for FES10 Electric Door Strikes
The FSH FES10-EL15 Extension Lip is a 15mm strike lip designed for use with compatible FSH FES10 and FES10M electric door strikes. It extends the edge of the electric strike faceplate to provide the door latch with a clear path into the strike keeper.
Extension lips are commonly required where the door-frame profile would otherwise interfere with the latch as the door opens or closes. The additional 15mm of coverage can help protect the frame, improve latch clearance and produce a neater professional installation.
Key Features
-
15mm extension lip for compatible FSH electric strikes
- Designed to suit the FSH FES10 Series
- Compatible with FES10 non-monitored electric strikes
- Compatible with FES10M monitored electric strikes
- Provides additional clearance between the latch and door frame
- Allows the latch to enter the electric strike jaw freely
- Helps prevent the latch from contacting or damaging the frame
- Suitable for timber and aluminium door-frame installations
- Uses the pre-drilled extension-lip mounting points on the strike
- Designed for professional access control installations
Why Use an Electric Strike Extension Lip?
An extension lip may be required when the standard faceplate does not extend far enough beyond the edge or profile of the door frame. Without sufficient clearance, the door latch can contact the frame before reaching the electric strike keeper.
The FES10-EL15 extends the strike lip by 15mm, helping guide the latch cleanly into the keeper while reducing the risk of interference with the frame. It can also provide a neater finish around the strike installation.
Compatible Electric Strikes
-
FSH FES10: non-monitored ANSI-footprint electric strike
-
FSH FES10M: monitored ANSI-footprint electric strike
The FES10 Series electric strikes are pre-drilled for extension lips, allowing the compatible accessory to be securely attached during installation.
Technical Specifications
| Brand |
FSH |
| Model |
FES10-EL15 / FSHFES10-EL15 |
| Product Type |
Electric strike extension lip |
| Extension Length |
15mm |
| Approximate Dimensions |
85mm x 15mm |
| Compatible Models |
FSH FES10 and FES10M |
| Suitable Frames |
Commonly used with timber and aluminium frames |
| Electrical Connection |
Not required |
Check the Required Lip Length
FSH extension lips are available in different lengths to accommodate different door-frame profiles. The distance between the electric strike faceplate and the outside edge of the frame should be measured before ordering.
This model provides a 15mm extension. A longer extension lip may be required where the frame has a deeper or wider profile.
Installation Note
The extension lip should be securely fitted to the pre-drilled mounting points on the compatible electric strike. Correct alignment is important to ensure the door latch moves freely into the keeper without rubbing, binding or placing pressure on the strike mechanism.
Installation should be completed by a qualified locksmith, security technician or access control installer. Confirm the electric strike model and required extension length before ordering.
Why Choose the FSH FES10-EL15?
- Purpose-designed for the FSH FES10 Series
- Suitable for monitored and non-monitored FES10 models
- Improves latch clearance around deeper door frames
- Helps reduce contact between the latch and frame
- Provides a clean and professional installation finish
