Bosch Fingerprint Reader Black, CM728B

SKU F.01U.275.883 CM728B
by Bosch
Availability:
in stock, ready to be shipped

Bosch Fingerprint Reader Black

Model : CM728B

Features Separate indicators show door and alarm status; built in sounder provides alarm warning Lock output and egress input to simplify wiring, with built in tamper switch Haptic feedback enhances user operation Adjustable volume control Anti replay and anti substitution protection.

  • Separate indicators show door and alarm status;built in sounder provides alarm warning
  • Lock output and egress input to simplify wiring,with built in tamper switch
  • Haptic feedback enhances user operation
  • Adjustable volume control
  • Anti replay and anti substitution protection
Sale Sale
Original price $568.23
Original price $568.23 - Original price $568.23
Original price $568.23
Current price $437.10
$437.10 - $437.10
Current price $437.10

✓ Flat Rate Shipping $17.50 ✓ Free Delivery over $500

Shipping

Shipping Policy

Free Shipping

  • Free shipping for orders over $500.00.

Postage Charge

  • We charge a flat rate of AUD $17.50 for every order regardless of quantity.

Delivery Policy

  • All prices displayed on this website exclude shipping costs

Delivery Method

  • C.T.C Communications delivers products Australia wide using Australia Post delivery service.

International Shipping

  • We currently do not ship good overseas.

Parcel Tracking

  • All packages sent are registered with Australia Post E Parcel service and provide full tracking once it leaves our premises until it arrives at its destination. A signature on arrival is necessary for shipment.
  • Please ensure your mobile number and emails are entered into your order to help us with this automated tracking service.
Delivery Times

Delivery Times

  • Orders are dispatched within 2 business days and shipping times are estimated at between 3-7 business days depending on your location within Australia.

Transit Times

  • We are not responsible for Australia Post transit times as they do vary depending upon your destination.

Dispatch Times

  • Australia Post picks up from our office is at 2:30pm weekdays, orders placed after 2:30pm that day will not be in the post until the following day.

Public Holidays and Weekends

  • Please note, no goods are dispatched on weekends or public holidays.

Express Post

  • Express orders shall be dispatched within 24-48 working hrs. Staff will be in contact if there is any delay. Delivery time will be dependent of your location within Australia. .

P.O Box Delivery

  • We delivery to PO Boxes and Parcel Lockers but ideally work addresses are more suitable for a signed delivery.

Business to Business with Sydney

  • For companies in Sydney we utilise our local courier service Couriers Please.

Pick up in-store

  • Pick up is available at our Seven Hills showroom, Unit 31/1 Prime Drive, Seven Hills, NSW, 2147.

Urgent Deliveries

  • If you require this parcel urgently please call our office on 1300 552 282 to ensure all items are in stock prior to purchasing.
Refund Policy

Trade Accounts

To learn more about our trade accounts and how you can save money on your next security purchase.

Apply Now


Bosch CM728B Fingerprint Reader in Black, allow access to turn on or off your Bosch control panel via the fingerprint scanner, for internal use only, ideal for businesses.

Model : CM728B

The additional of a fingerprint reader to your installation will allow users to turn areas on and off or open a door simply by presenting their unique fingerprint credential to the reader.

Specifications

  • Separate indicators show door and alarm status; built in sounder provides alarm warning
  • Lock output and egress input to simplify wiring, with built in tamper switch
  • Haptic feedback enhances user operation
  • Adjustable volume control
  • Anti replay and anti substitution protection

The fingerprint reader features 3D pixel sensing technology and can read virtually any finger; wet or dry. The sensors hard-coating protects against scratches, impacts and everyday wear-and-tear and provides in excess of 15KV electrostatic discharge isolation. The fingerprint reader includes red, green and blue indicators which are used to show area or door lock status at all times. To simplify installation, an egress input and lock output are also provided.

Unlike other systems, the readers are fully integrated with the control panel, which means that fingerprint credentials are automatically transferred between other readers on the system, reducing programming and installation time. Credentials can also be uploaded using the Solution Link RAS software for backup purposes and can even be copied from one panel to another, simplifying configuration for users with multiple sites. Various options can be configured via the Devices Keypad & Reader menu in panel programming. User access events are stored in the panel log and can also be reported if required.

Functions

A large blue reader status indicator is provided in the finger placement area to simplify user enrollment and day to day operation. The readers also include haptic technology that takes advantage of the users sense of touch by applying vibrations to the users finger during analysis and enrollment of fingerprint credentials.

Certifications and approvals

Code: N12138CE: EN 55022:2010, EN60950-1:2001

Tele permit: PTC 211/12/017

Technical specifications

  • Power Requirements Operating
  • Voltage: 10.0V DC 14.5V DC @ 100mAConnections
  • Format: Proprietary Lock Output:
  • Protected open collector transistor output 500mAEgress Input: Love (Ov) to trigger.
  • Can be disabled via software control
  • Environmental Considerations Temperature: -30o to 55oC
  • Operating Humidity: 5% to 85% at 30oC non-condensing
  • Enclosure Dimensions: 74(W) x 23(D) x 116(H)mm
  • Warranty: 3 years

Shop CTC Communications for best deals Bosch Security Products


Bosch Security Warranty
  • Bosch security products are covered by a 3 year Manufacturer Warranty.
  • Exclusion are labour for installed by others.
  • CTC Communications provides a 1 year warranty on labour when the security product is installed by our Team.
  • Freight Cost is excluded from Warranty, unless the product is dead upon arrival.
