HiLook 32ch NVR NVR-232MH-K-16P with No HDD

HiLook 32 Channel Network Video Recorder – NVR-232MH-K-16P

The HiLook NVR-232MH-K-16P is a high-capacity 32-channel network video recorder designed for advanced surveillance systems in commercial and enterprise environments. With 16 built-in PoE ports, it simplifies camera connectivity, supports up to 256 Mbps bandwidth, and handles ultra-HD decoding up to 12MP resolution.

Engineered for performance and scalability, this recorder also features AI-enhanced smart detection, efficient H.265+ compression, and remote access via Hik-Connect, making it a powerful solution for multi-camera installations.

🛠 Model: NVR-232MH-K-16P
📦 Note: Hard drives not included – sold separately.

🔍 Key Features

🎥 Supports 32 IP Cameras – Easily manage large-scale surveillance networks with up to 32 camera inputs.

🔌 16x PoE Ports – Directly power up to 16 cameras with simplified cabling and installation.

🎞 Multi-Format Compression – Compatible with H.265+, H.265, H.264+, and H.264 video formats for bandwidth savings.

🧠 AI-Powered Detection – Minimises manual monitoring with intelligent motion and event classification.

🖥 Ultra-HD Decoding – Supports up to 2-ch @ 12MP, 3-ch @ 8MP, 6-ch @ 4MP, or 12-ch @ 1080p simultaneous decoding.

🌐 High Bandwidth Capacity – Handles up to 256 Mbps incoming bandwidth for smooth, uninterrupted video performance.

🗄 Large Storage Support – Dual SATA interfaces supporting up to 10TB per drive (20TB total capacity).

🖴 Dual Output – HDMI (4K) and VGA for flexible monitoring setups.

🎧 Audio Support – RCA input/output with two-way audio functionality.

📱 Remote Access – View and manage recordings anytime with the HiLookVision app

🖥 Specifications

📹 Video and Audio

• IP Camera Inputs: 32

• HDMI Output: Up to 4K (3840 × 2160 @ 30Hz)

• VGA Output: Up to 1080p

• Audio Output: 1-ch RCA

• Two-Way Audio: 1-ch RCA input

🔄 Decoding & Playback

• Decoding: 2-ch @ 12MP / 3-ch @ 8MP / 6-ch @ 4MP / 12-ch @ 1080p

• Synchronous Playback: Up to 16-ch

• Supported Resolutions: 12MP / 8MP / 6MP / 4MP / 1080p and below

🌐 Network & PoE

• Protocols: TCP/IP, DHCP, Hik-Connect, DDNS, NTP, HTTPS, SMTP

• LAN Port: 1x RJ-45, 10/100/1000 Mbps

• PoE Ports: 16x IEEE 802.3af/at

• PoE Power Budget: ≤ 200W

💾 Storage & Interface

• HDD Bays: 2x SATA, supports up to 20TB total (10TB per bay)

• USB: 1x USB 3.0, 1x USB 2.0

⚙️ General

• Power Supply: 100240 VAC, 5060 Hz

• Power Consumption: ≤ 15W (without PoE)

• Operating Temp: -10°C to +55°C

• Dimensions: 385 × 315 × 52 mm

Backed by a 3-Year Manufacturer Warranty.
📦 Fast Australia-wide shipping available.
