Bosch Blue Line Gen2 Standard PIR Motion Detectors, ISC-BPR2-W12

Bosch Blue Line Gen2 Standard PIR Motion Detector – ISC-BPR2-W12

Model: ISC-BPR2-W12

Enhance your alarm system with the reliable performance of the Bosch Blue Line Gen2 Standard PIR Motion Detector ISC-BPR2-W12. Designed for professional-grade intrusion detection, this wired PIR sensor delivers consistent, accurate motion detection with minimal false alarms.

The Blue Line Gen2 series uses advanced optics and intelligent signal processing to provide sharp detection across the entire coverage area. Ideal for residential homes, offices, retail stores, and commercial premises, this detector integrates seamlessly with leading alarm panels including Bosch Solution systems.

Key Features of the ISC-BPR2-W12

Wall-to-Wall Coverage
12m x 12m (40ft x 40ft) detection range for broad room protection.

High-Density Optical System
77-zone, 7-layer Fresnel lens pattern for sharply focused detection throughout the field of view.

Selectable Look-Down Lens
Includes 3 additional look-down zones to protect directly beneath the detector.

Dynamic Temperature Compensation
Automatically adjusts sensitivity to maintain superior catch performance in changing environmental conditions.

Flexible Mounting Height – No Adjustments Required
Install at recommended height without reconfiguration, reducing setup time.

Self-Locking Enclosure with Integrated Bubble Level
Faster, straighter installation while minimising false alarms.

Compact Design
Dimensions: 105mm (H) x 61mm (W) x 44mm (D)

⚠️ Note: This model is not pet-friendly and is not recommended for properties where pets move freely while the system is armed.

Advanced Detection Performance

The Blue Line Gen2 PIR uses precision-engineered Fresnel lenses to generate sharply focused infrared images across its coverage field. Combined with intelligent processing and temperature compensation, it delivers:

• Improved intruder catch performance

• Reduced false alarm triggers

• Reliable operation in varying climates

• Consistent detection across the full 12m range

This makes it a dependable solution for both residential and commercial security installations.

Ideal For

• Homes (non-pet environments)

• Offices and professional suites

• Retail stores

• Warehouses

• Internal room protection within alarm systems

Compatibility

The ISC-BPR2-W12 is compatible with most wired alarm control panels, including:

• Bosch Solution 2000

• Bosch Solution 3000

• Bosch Solution 6000

It can also be integrated into broader security systems with reed switches, glass break sensors, and external sirens.

Why Choose Bosch Blue Line Gen2?

Bosch is globally recognised for engineering excellence in electronic security. The Blue Line Gen2 range is designed for:

• Faster installations

• Reduced service call-backs

• Long-term reliability

• Consistent detection accuracy

When you choose Bosch, you're investing in proven security technology trusted worldwide.

Technical Specifications

• Model: ISC-BPR2-W12

• Detection Range: 12m x 12m

• Optical Zones: 77 zones, 7 layers

• Look-Down Zones: 3

• Mounting Height: Flexible, no adjustment required

• Dimensions: 105 x 61 x 44 mm

• Application: Indoor use
