Aiphone JV-1FD Video Expansion Station

Aiphone JV-1FD Intercom expansion station Hands-Free Video System for intercom kit JV Series

The JV-1FD is an expansion station for the JV Series. The station provides an extra monitor for JV Series systems. One can be added per JV system, is sold separately, and is intended to be used only with the JVS-1A or JVS-1F box sets.

Key Features:

✅ Intercom Internal Monitor Station (JV-1FD)

• 7” screen for clear video identification and monitoring
• Slim, modern design to complement any space
• Hands-free communication with push-to-talk (simplex) option

Technical Specifications:

🔹 Power Source: 24V DC (PS-2420UL)
🔹 Door Release Options:

• Master/Expansion Station & Door Station: N/O dry contact, 24V AC/DC, 1A
• Second Door Station Output: N/O wet contact, 500mA (max), 12V DC

🔹 Communication Modes:

• Hands-free (VOX) or push-to-talk (simplex)

🔹 Wiring Requirements:

• Door Station to Master Station: 2-conductor, mid-cap, solid, non-shielded (Aiphone #871802)
• Door Station to Expansion Station: 2-conductor, mid-cap, solid, non-shielded (Aiphone #871802)
• Expansion to Master Station (without door release): 4-conductor, mid-cap, solid, non-shielded (Aiphone #871804 OR 2 runs of Aiphone #871802)
• Expansion to Master Station (with door release): 6-conductor, mid-cap, solid, non-shielded (Aiphone #871802 + #871804 OR 3 runs of Aiphone #871802)

🔹 Maximum Distance:

• Door Station to Master Station: 165' (22AWG) / 330' (18AWG)
• Door Station to Expansion Station: 165' (22AWG) / 330' (18AWG)
• Expansion Station to Master Station: 165' (22AWG) / 330' (18AWG)
• Power Supply to Master Station: 16' (22AWG) / 33' (18AWG)

Perfect for residential or commercial settings, the Aiphone Video Master Station, JV-1FD is an ideal intercom when combined with JV-door station.

🔹 Available now at CTC Communications – order today!

Benefits of A Home Intercom

1. Enhanced Security: One of the primary reasons homeowners opt for intercom systems is to bolster their security. These systems allow you to verify the identity of visitors before granting them access to your home. Whether it's a delivery person, a repair technician, or simply a friend or family member, you can safely communicate and confirm their identity without having to open the door.

2. Convenient Communication: Intercom systems provide a convenient way for family members to communicate with each other throughout the house. Instead of shouting across rooms or running up and down stairs, you can simply press a button and talk through the intercom. This is especially useful in larger homes where communication can be challenging.

3. Access Control: Home intercom systems often come with access control features, allowing you to remotely grant or deny access to your property. This is particularly beneficial if you have a gated entry or want to manage access to specific areas within your home, such as a home office or private quarters.

4. Monitor Front Door Activity: Modern intercom systems are equipped with video capabilities, enabling you to see who is at your front door. This feature is especially valuable for screening unexpected visitors or monitoring package deliveries when you're not at home. Some systems even allow you to capture images or video footage for future reference.

5. Deterrence Factor: The mere presence of an intercom system can act as a deterrent to potential intruders. When burglars see that your home has an intercom system, they may think twice before attempting a break-in, knowing that their presence will be easily detected and recorded.

6. Home Automation Integration: Many home intercom systems can integrate with your home automation setup, allowing you to control other smart devices in your home. You can use voice commands to adjust the thermostat, turn on lights, or even lock/unlock doors, making your home smarter and more efficient.

7. Surveillance Solution- Many brands such a Dahua can integrate surveillance camera viewing into your intercom system.
8. Peace of Mind: Knowing that you can communicate with family members, monitor your property, and control access to your home provides a sense of security and peace of mind. Whether you're away for the weekend or simply relaxing in your backyard, you'll have the assurance that you can stay connected to your home.
