Best For: Retail, shopping centres, offices, education facilities, warehouses and large commercial spaces needing 360° panoramic coverage, people-counting heatmaps, two-way audio and 6MP detail from a single camera position.
Hikvision DS-2CD6365G1-IVS 6MP DeepinView Fisheye Network Camera
The Hikvision DS-2CD6365G1-IVS is a 6MP DeepinView fisheye network camera designed to provide full 360° panoramic surveillance from a single camera position. Its 1/1.8-inch sensor captures up to 2560 × 2560 resolution, while the 1.16mm fisheye lens provides a 180° horizontal and 180° vertical field of view that can be dewarped into panoramic and PTZ-style views.
The camera also adds deep-learning heatmap analytics, people counting, built-in microphones and speaker for two-way audio, Smart IR illumination up to 15 metres, 120dB WDR, microSD storage up to 256GB, IP67 weather resistance and IK10 vandal protection.
Key Features of the DS-2CD6365G1-IVS
-
6MP resolution up to 2560 × 2560
-
360° panoramic surveillance from one fisheye camera position
- 1.16mm F2.25 fisheye lens
- Deep-learning heatmap and people counting
-
Up to 20 live-view display modes across multiple mounting types
-
Built-in microphones and speaker for two-way audio
-
120dB WDR for challenging high-contrast scenes
- Smart IR illumination up to 15m
-
On-board microSD storage up to 256GB
- IP67 weather protection
- IK10 vandal resistance
360° Panoramic Coverage
The fisheye lens is designed to capture the entire surrounding scene from a single mounting point. When ceiling-mounted, the camera can provide full-room situational awareness with fewer blind spots than conventional fixed cameras.
Hikvision supports multiple dewarping modes so operators can view the fisheye image as panoramic strips, PTZ-style regions or other corrected views that are easier to interpret during live monitoring and playback.
DeepinView Heatmap & People Counting
Deep-learning analytics allow the camera to count people and generate an intuitive heatmap showing how people move through monitored spaces. This makes the DS-2CD6365G1-IVS useful not only for security, but also for understanding customer flow and space utilisation in retail and commercial environments.
Built-in Two-Way Audio
The camera includes four built-in microphones and one built-in speaker, supporting real-time two-way audio communication. It also provides separate audio input and output connections for broader system integration.
120dB WDR & 15m Smart IR
120dB WDR helps balance bright and dark areas within the same scene, while three independently controlled IR illuminators provide visibility up to 15 metres in low or zero-light environments.
Outdoor & Vandal-Resistant Protection
The DS-2CD6365G1-IVS is rated IP67 for water and dust resistance and IK10 for vandal resistance. Hikvision classifies this model as having no specific anti-corrosion protection, so it should not be positioned as a marine or specialist coastal camera.
Ideal Applications
- retail stores and shopping centres
- office reception areas and open-plan workplaces
- building lobbies and public spaces
- schools, universities and training facilities
- warehouses and logistics facilities
- conference rooms and large meeting spaces
- sites requiring people-flow analytics and wide panoramic surveillance
Technical Specifications
| Brand |
Hikvision |
| Model |
DS-2CD6365G1-IVS |
| Camera Type |
DeepinView IR network fisheye camera |
| Image Sensor |
1/1.8" Progressive Scan CMOS |
| Maximum Resolution |
2560 × 2560 (6MP) |
| Minimum Illumination |
Colour: 0.01 Lux @ F2.25; B/W: 0.005 Lux @ F2.25; 0 Lux with IR |
| Lens |
1.16mm fixed fisheye, F2.25 |
| Lens Field of View |
180° horizontal / 180° vertical |
| Panoramic Coverage |
360° panoramic scene coverage when appropriately mounted |
| IR Distance |
Up to 15m Smart IR; 3 IR illuminators |
| Wide Dynamic Range |
120dB WDR |
| Analytics |
Deep-learning heatmap and people counting |
| Display Modes |
Up to 20 live-view modes depending on mounting and dewarping configuration |
| Built-in Audio |
4 microphones and 1 speaker; two-way audio support |
| External Audio |
1 audio input / 1 audio output |
| On-board Storage |
microSD / microSDHC / microSDXC up to 256GB |
| Network |
Gigabit Ethernet 10/100/1000 Mbps |
| Protection |
IP67 / IK10 |
| Anti-Corrosion Classification |
No specific protection |
| Operating Temperature |
-40°C to 60°C |
| Weight |
Approx. 715g |
| CTC SKU |
DS-2CD6365G1-IVS |
